SCROLL DOWN TO SEE ALL INFORMATION AND SPECIFICATIONS FOR THIS FIXTURE!
SPEC SHEET WITH PHOTOMETRICS (PDF):
USER / INSTALLATION GUIDE (PDF):
SPEC SHEET FOR THE OPTIONAL EMERGENCY BATTERY BACKUP (PDF):
2X4 Size 50 Watt Premium Commercial LED Flat Panels. Replaces 100-120+ Watt CFL fixtures while consuming at least 50% less electricity! Never change another bulb or ballast again! Just install these and forget about them for AT LEAST 10-20 years! These LED Flat Panels are especially perfect for hard-to-reach locations where re-lamping can be a costly (and dangerous) pain in the you know what! Go Smart. Go with our EZ LED Flat Panels!
DLC PREMIUM LISTED:
Great News! These models are eligible for even greater rebate savings from most power companies accross the USA, and offer industry-leading effiency of 130+ Lumens Per Watt!
LIGHT COLOR OUTPUTS AVAILABLE:
These LED Flat Panels are available with light color outputs of 5000K Cool white or 4000K Pure White. See images above for light color examples.
RECOMMENDED APPLICATIONS & MOUNTING OPTIONS:
General indoor illumination for Office, Home, Retail, Hospitals, etc. Designed to lay recessed into an existing 2X4 Ceiling Panel and can also be recessed mounted into most ceilings. Surface and suspended mount kits for this fixture are also optionally available.
BELOW PHOTOS SHOW LED FLAT PANEL FIXTURES IN ACTION! CLICK ANY TO ENLARGE!
ADDITIONAL SPECIFICATIONS FOR THIS LED FLAT PANEL BELOW
CONSTRUCTION: Die Cast Cold Rolled Steel Housing with high Strength Frosted Acrylic Lens Diffuser.
LIGHT DISTRIBUTION: This LED Flat Panel offers a wide 150° Beam Spread, offering maximum useful lumen output with little to no light loss! CFL Troffers typically lose 50-70% of their lumens in wasted light shooting backwards into the fixture. With these LED Flat Panels, all of the available lumens are put into use, as no light shoots backwards from the source!
INPUT VOLTAGES AVAILABLE: Designed to run on voltages ranging from 100VAC ~ 277VAC. Power Supply included will automatically determine voltage (if between these ranges). For other voltages such as 347VAC, please call us.
LED RATED LIFE: 100,000+ Hours, meaning if you were to use these fixtures for 8 hours per day, 365 days per year, these LED fixtures will last you over 34 YEARS! To put this into perspective, if you were to run this fixture 24 hours a day, 365 days per year, it would stay lit for over 11 years!!!
CRI: >82. The higher the CRI (Color Rendering Index) rating, the better! CRI represents the amount of the spectrum used in the light output, i.e. the higher the value, the better the color clarity you will see from the light! LED doesn’t just save you money in energy costs, but it gives you a BETTER light versus Fluorescent. You will SEE the difference!
INSTALLATION & MOUNTING: Recess mounts (lays in) easily into an existing 2’x4′ Ceiling Panel, installing in minutes. Can also be installed into just about any ceiling by cutting an appropriate sized hole into existing drywall. Also applicable for new construction use. Surface and Suspended Mount Kits are also optionally available.
CERTIFICATIONS (LISTINGS): UL & cUL Listed, DLC Premium Listed, California Title 24 Approved, CE and RoHS Certified. Rated for indoor dry or damp location use.
