900 Watt Stainless Steel Multi-Tap (12v-22v) Outdoor Transformer

$589.99

SKU: SRTO-SS-900-22V

In Stock

Quantity:
x

Product Description

SCROLL DOWN TO SEE OUR VOLTAGE DROP CHART.

This Transformer is OVER-RATED to ensure your ability to load the transformer to the maximum wattage specified and have worry-free operation! Stainless Steel MULTI-TAP 12v Low Voltage 900 Watt Outdoor Transformer. Made out of Brushed Stainless Steel, this transformer carries a 10 YEAR GUARANTEE! Rated for outdoor wet location, you may also order this transformer with optional Timer and/or Photocell when ordering this transformer. Made in the USA!

SPECIFICATIONS:
-MATERIAL: Stainless Steel Construction
-MAX. LOAD: 900 Watts
-TAPS: 12v, 13v, 14v, 15v, 16v, 17v, 18v, 19v, 20v, 21v, 22v
-TERMINAL BLOCKS:
Comes Standard with Terminal Blocks for easy installation and wiring,
no wire nuts necessary!
-TIMER: Available Option when ordering this transformer
-PHOTOCELL: Available Option when ordering this transformer
-MOUNTING: UL Listed Wet Location, Can Be mounted just about anywhere!
-WARRANTY: 10 Year Guarantee!

The numbers in red are the recommended maximum run (in feet) recommended per single run without noticable voltage drop. Voltage drop, as seen below, is determined by the thickness (gauge) of the wire and the load (watts) placed on it. The longer the run, the lower the voltage when it reaches the fixture. Please follow the chart below to determine what you need to set up your low voltage wiring system. We never recommend placing more than 250 Watts on a single 12 Guage run, please use 10 Guage wire if doing so. The voltage chart below is to be used as a guide only. Please keep in mind that we are not licensed contractors and we always recommend consulting with a licensed electrical contractor before doing any electrical work. We recommend using a volt meter to determine exactly what voltage is running into your fixtures. We are not responsible for any damage that may result from the use or mis-use of this information.



MAXIMUM RECOMMENDED RUNS
Voltatge Tap
Wire Gauge
100-150 Watts
151-200 Watts
201-250 Watts
251-300 Watts
12 Volts
10 Gauge
25 Feet
17 Feet
13 Feet
11 Feet
12 Gauge
16 Feet
11 Feet
9 Feet
Not Recommended
13 Volts
10 Gauge
80 Feet
55 Feet
40 Feet
33 Feet
12 Gauge
50 Feet
35 Feet
24 Feet
Not Recommended
14 Volts
10 Gauge
135 Feet
95 Feet
70 Feet
55 Feet
12 Gauge
86 Feet
59 Feet
42 Feet
Not Recommended
15 Volts
10 Gauge
192 Feet
135 Feet
100 Feet
75 Feet
12 Gauge
121 Feet
80 Feet
60 Feet
Not Recommended
16 Volts
10 Gauge
250 Feet
170 Feet
125 Feet
100 Feet
12 Gauge
160 Feet
105 Feet
80 Feet
Not Recommended
17 Volts
10 Gauge
310 Feet
208 Feet
155 Feet
125 Feet
12 Gauge
195 Feet
132 Feet
99 Feet
Not Recommended
18 Volts
10 Gauge
365 Feet
245 Feet
185 Feet
148 Feet
12 Gauge
227 Feet
155 Feet
115 Feet
Not Recommended
19 Volts
10 Gauge
420 Feet
280 Feet
214 Feet
170 Feet
12 Gauge
265 Feet
175 Feet
135 Feet
Not Recommended
20 Volts
10 Gauge
478 Feet
318 Feet
243 Feet
190 Feet
12 Gauge
305 Feet
200 Feet
150 Feet
Not Recommended
21 Volts
10 Gauge
535 Feet
360 Feet
270 Feet
215 Feet
12 Gauge
340 Feet
224 Feet
170 Feet
Not Recommended
22 Volts
10 Gauge
590 Feet
395 Feet
295 Feet
235 Feet
12 Gauge
375 Feet
250 Feet
188 Feet
Not Recommended
